產品性能

Product performance：

低照度圖像傳感器Low light image sensor

日夜兩用全天候觀測Day and night dual-use all-weather observation

一鍵錄像或拍照One click recording or photography

WIFI連接手機實現同步觀看和遠程遙控

WIFI connection to mobile phone for synchronized viewing and remote control

流暢的數碼倍率變焦（放大或縮小）Smooth digital zoom (zoom in or out)

戶外GPS定位Outdoor GPS positioning

圖像亮度的調節Adjusting image brightness

超寬帶多層增透膜 Ultra wideband multilayer anti reflective film

支持4G-128G范圍內的micro SD卡   Supports micro SD cards in the 4G-128G range

支持多種電源方式 Supports multiple power supply methods

支持安裝三腳架Support the installation of tripods

產品參數

Product parameters：

型號model

DM1920-3X

傳感器分辨率Sensor resolution

1600x1600

放大倍率Magnification rate

15-45連續變倍 15-45 continuous doubling

視場角度（度,，°）（D,、H、V分別是對角,、水平、垂直三個方向Field of view angle (degrees, degrees) (D, H, V are diagonal, horizontal, and vertical directions respectively)

D=10°H=8°V=5°

焦距focal length

50

視度調節范圍（屈光度）Visual adjustment range

+5°/-5°

物鏡焦距Objective lens focal length

50mm

照片質量Photo quality

1920x1080

錄像質量Recording quality

1920x1080

觀察模式

Observation mode

晝/夜兩種模式（彩色/黑白）

Two modes of day/night (color/black and white)

夜間模式擋位Night mode gear

1-4擋（N1/N2/N3/N4）

屏幕亮度調節Screen brightness adjustment

有（1-3擋）yes

紅外輔助距離Infrared assisted distance

1-500米（根據目標及環境不同有所差異）

1-500 meters (varies depending on target and environment)

電池種類Battery type

18650鋰電池（1節）/18650 lithium battery (1 unit)

電池電壓范圍Battery voltage range

2.6-4.2V

其他電源方式

Other power supply methods

支持（如充電寶、直流電,、車載電源等）

Support (such as power bank, DC, car power supply, etc.)

低電指示Low battery indication

有yes

TF內存卡端口TF memory card port

有（支持4G-128G）Yes (supports 4G-128G)

USB端口 USB port

有Yes（Type-C）

WiFi連接手機APP

WiFi connection to mobile app

支持iOS & Android (圖像視頻傳輸/遠程遙控)可一對多Supports iOS&Android (image and video transmission/remote control) for one to many

WIFI連接APP有效距離

Effective distance of WIFI connection to APP

20米內

Within 20 meters

GPS

有Yes

電子羅盤Electronic compass

有Yes

氣壓計Barometer

有Yes

俯仰角&水平角Pitch angle&horizontal angle

有Yes

聲音記錄Sound recording

有Yes

日期記錄Date Record

有Yes

語言選擇Language selection

中文、英文Chinese, English

防塵防水等級Protection grade

生活防水Domestic waterproofing

外接三腳架External tripod

支持（1/4螺絲）

產品尺寸Product size

154X63X80mm

重量weight

342g
